Features

• Built-in Wi-Fi
• Active Energy Control
• Google Assistant
• Smart Diagnosis
• Temperature Control
• Sleep Easy
• The 'Comfort Air' option
• Smart Inverter Compressor„¢

Performance

• Cooling Capacity (Rating): 2.6kW
• Heating Capacity (Rating): 3.2kW
• Cooling Capacity Range (min ~ max): 0.89 ~ 3.70
• Heating Capacity Range (min ~ max): 0.89 ~ 5.0
• Power Input: Cooling: 600kW Heating: 743kW
• Rated Running Current: Cooling: 3.0A Heating: 3.3A
• EER Cooling: 4.33 W/W
• AEER Cooling: 4.26 W/W
• COP Heating: 4.31 W/W
• ACOP Heating: 4.25 W/W
• Air Flow Rate (Indoor Max): Cooling: 720/660/540/330 Heating: 750/660/540/390
• Indoor Noise (dB(A) ± 3) (Sound Pressure Level¹) (H/M/L/S): 48/42/37/27/19
• Outdoor Noise (dB(A) ± 3) (Sound Pressure Level¹) (H/M/L/S): Cooling: 49 Heating: 51
• Moisture Removal (l/h): 1.10

Technical

• Refrigerant Charge: 800g
• Refrigerant Type: R32
• Pre-Charge Lenth: 7.5m
• Pipe Run (Min / Max): 3m/20m
• Max. Elevation Distance: 10m
• Piping Connection Heat Insulation: Both liquid and gas pipes
• Circuit Breaker Size: 15 Amps
• Additional Refrigerant (g/meter): 20
• Refrigerant Control: Electronic Expansion Valve
• Outdoor Operating Range (DB): Cooling -15 ~ 48°C Heating -15 ~ 24°C
• Outdoor Operating Range (WB): Heating -15 ~ 18°
• Pipe Size Connection (Ø): Liquid: 6.35mm (1/4 inch) Gas: 9.52mm (3/8 inch)
• Drain Hose Size (O.D/I.D): 20mm/15mm
• Pipe Connection Method (Indoor/Outdoor): Flared/Flared
• Outdoor Sound Power Level (SWL): 65 dB(A)
• Outdoor Compressor: Twin Rotary
• Outdoor Condenser: Gold

Energy Consumption

• Energy Rating (Heating): 5.0 STAR
• Energy Rating (Cooling): 4.5 STAR
• Power Supply: 1Ph 220~240V 50Hz
• Power Supply Cable: 3 Core + Earth
• Power Supply to Unit: Outdoor
• Power and Communication Cable: 4 x 1.0 ( Including Earth)

Dimensions

• Inddor (W x H x D) mm = 837 x 308 x 189 mm 9.1 kg
• Outdoor (W x H x D) mm = 770 x 545 x 288 mm 34.1 kg

Warranty

• 5 year parts and labour + 5 year limited parts warranty on the compressor
